Material contains a batteryYes
Weight1.5 kg
Weight3.3 lb
Sound standardISO15744
Vibration value<2.5 m/s²
Model typeAngle
Sound pressure<70 dB(A)
Vibration standardISO28927-2
Square drive3/8 in
Torque range min6 Nm
Torque range max30 Nm
Torque range max22 ft lb
BatteryLi-Io 18 V
Shut-off systemTransducer
KC certifiedYes
Height41.8 mm
Length470.8 mm
TensorSTB
Torque range min4.5 ft lb
ETL control number3008099
ETL listedYes
Free speed 9.6 V380 r/min
Motor voltage18 V
Type of battery1 Li-ion
Weight of battery65 g
Motor power1080 W
FCC IDPVH0965
IC ID5325A-0965
EAC certifiedYes
CMIIT ID2016AJ1533
WEEE5 - Small equipment <50cm
Communication typeBluetooth/WLAN
ETL text6 - 62841-2-2
KC IDR-R-50A-STB3464
EC standardEN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 301 893 V2.1.1, EN 50 566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2019, EN 61000-6-4:2007+A1:2011, EN 62841-1:2015, EN 62841-2-2:2014 + AC:2015
EU directives2006/42/EC (MD), 2011/65/EU (RoHS), 2014/53/EU (RED), 2015/863/EU (RoHS amendment)
速度344 r/min
Speed range max344 r/min
Output typeSquare, Male
Output size3/8"
UK legislationS.I. 2008/1597, S.I. 2012/3032, S.I. 2017/1206
UK standardEN 300 328 V2.2.2, EN 300 440 V2.1.1, EN 301 489-1 V2.1.1, EN 301 489-17 V3.1.1, EN 301 893 V2.1.1, EN 50 566:2017, EN 55014-1:2017, EN 55014-2:2015, EN 61000-6-2:2019, EN 61000-6-4:2007+A1:2011, EN 62841-1:2015, EN 62841-2-2:2014 + AC:2015
EU SAR value0.54 W/kg
Tool familySTB
